A Coding Implementation to Simulate Practical Byzantine Fault Tolerance with Asyncio, Malicious Nodes, and Latency Analysis

import asyncio
import random
import time
import hashlib
from dataclasses import dataclass, field
from typing import Dict, Set, Tuple, Optional, List
import matplotlib.pyplot as plt

PREPREPARE = “PREPREPARE”
PREPARE = “PREPARE”
COMMIT = “COMMIT”

@dataclass(frozen=True)
class Msg:
typ: str
view: int
seq: int
digest: str
sender: int

@dataclass
class NetConfig:
min_delay_ms: int = 5
max_delay_ms: int = 40
drop_prob: float = 0.0
reorder_prob: float = 0.0

class Network:
def __init__(self, cfg: NetConfig):
self.cfg = cfg
self.nodes: Dict[int, “Node”] = {}

def register(self, node: “Node”):
self.nodes[node.nid] = node

async def send(self, dst: int, msg: Msg):
if random.random() < self.cfg.drop_prob:
return

d = random.uniform(self.cfg.min_delay_ms, self.cfg.max_delay_ms) / 1000.0
await asyncio.sleep(d)

if random.random() < self.cfg.reorder_prob:
await asyncio.sleep(random.uniform(0.0, 0.02))

await self.nodes[dst].inbox.put(msg)

async def broadcast(self, src: int, msg: Msg):
tasks = []
for nid in self.nodes.keys():
tasks.append(asyncio.create_task(self.send(nid, msg)))
await asyncio.gather(*tasks)

@dataclass
class NodeConfig:
n: int
f: int
primary_id: int = 0
view: int = 0
timeout_s: float = 2.0

class Node:
def __init__(self, nid: int, net: Network, cfg: NodeConfig, byzantine: bool = False):
self.nid = nid
self.net = net
self.cfg = cfg
self.byzantine = byzantine

self.inbox: asyncio.Queue[Msg] = asyncio.Queue()

self.preprepare_seen: Dict[int, str] = {}
self.prepare_votes: Dict[Tuple[int, str], Set[int]] = {}
self.commit_votes: Dict[Tuple[int, str], Set[int]] = {}

self.committed: Dict[int, str] = {}
self.running = True

@property
def f(self) -> int:
return self.cfg.f

def _q_prepare(self) -> int:
return 2 * self.f + 1

def _q_commit(self) -> int:
return 2 * self.f + 1

@staticmethod
def digest_of(payload: str) -> str:
return hashlib.sha256(payload.encode(“utf-8”)).hexdigest()

async def propose(self, payload: str, seq: int):
if self.nid != self.cfg.primary_id:
raise ValueError(“Only the primary can propose in this simplified simulator.”)

if not self.byzantine:
dig = self.digest_of(payload)
msg = Msg(PREPREPARE, self.cfg.view, seq, dig, self.nid)
await self.net.broadcast(self.nid, msg)
return

for dst in self.net.nodes.keys():
variant = f”{payload}::to={dst}::salt={random.randint(0,10**9)}”
dig = self.digest_of(variant)
msg = Msg(PREPREPARE, self.cfg.view, seq, dig, self.nid)
await self.net.send(dst, msg)

async def handle_preprepare(self, msg: Msg):
seq = msg.seq
dig = msg.digest

if self.byzantine:
if random.random() < 0.5:
return
fake_dig = dig if random.random() < 0.5 else self.digest_of(dig + “::fake”)
out = Msg(PREPARE, msg.view, seq, fake_dig, self.nid)
await self.net.broadcast(self.nid, out)
return

if seq not in self.preprepare_seen:
self.preprepare_seen[seq] = dig
out = Msg(PREPARE, msg.view, seq, dig, self.nid)
await self.net.broadcast(self.nid, out)

async def handle_prepare(self, msg: Msg):
seq, dig = msg.seq, msg.digest
key = (seq, dig)
voters = self.prepare_votes.setdefault(key, set())
voters.add(msg.sender)

if self.byzantine:
return

if self.preprepare_seen.get(seq) != dig:
return

if len(voters) >= self._q_prepare():
out = Msg(COMMIT, msg.view, seq, dig, self.nid)
await self.net.broadcast(self.nid, out)

async def handle_commit(self, msg: Msg):
seq, dig = msg.seq, msg.digest
key = (seq, dig)
voters = self.commit_votes.setdefault(key, set())
voters.add(msg.sender)

if self.byzantine:
return

if self.preprepare_seen.get(seq) != dig:
return

if seq in self.committed:
return

if len(voters) >= self._q_commit():
self.committed[seq] = dig

async def run(self):
while self.running:
msg = await self.inbox.get()
if msg.typ == PREPREPARE:
await self.handle_preprepare(msg)
elif msg.typ == PREPARE:
await self.handle_prepare(msg)
elif msg.typ == COMMIT:
await self.handle_commit(msg)

def stop(self):
self.running = False

def pbft_params(n: int) -> int:
return (n – 1) // 3

async def run_single_consensus(
n: int,
malicious: int,
net_cfg: NetConfig,
payload: str = “tx: pay Alice->Bob 5”,
seq: int = 1,
timeout_s: float = 2.0,
seed: Optional[int] = None
) -> Dict[str, object]:
if seed is not None:
random.seed(seed)

f_max = pbft_params(n)
f = f_max

net = Network(net_cfg)
cfg = NodeConfig(n=n, f=f, primary_id=0, view=0, timeout_s=timeout_s)

mal_set = set(random.sample(range(n), k=min(malicious, n)))
nodes: List[Node] = []
for i in range(n):
node = Node(i, net, cfg, byzantine=(i in mal_set))
net.register(node)
nodes.append(node)

tasks = [asyncio.create_task(node.run()) for node in nodes]

t0 = time.perf_counter()
await nodes[cfg.primary_id].propose(payload, seq)

honest = [node for node in nodes if not node.byzantine]
target = max(1, len(honest))

committed_honest = 0
latency = None

async def poll_commits():
nonlocal committed_honest, latency
while True:
committed_honest = sum(1 for node in honest if seq in node.committed)
if committed_honest >= target:
latency = time.perf_counter() – t0
return
await asyncio.sleep(0.005)

try:
await asyncio.wait_for(poll_commits(), timeout=timeout_s)
success = True
except asyncio.TimeoutError:
success = False
latency = None

for node in nodes:
node.stop()
for task in tasks:
task.cancel()
await asyncio.gather(*tasks, return_exceptions=True)

digest_set = set(node.committed.get(seq) for node in honest if seq in node.committed)
agreed = (len(digest_set) == 1) if success else False

return {
“n”: n,
“f”: f,
“malicious”: malicious,
“mal_set”: mal_set,
“success”: success,
“latency_s”: latency,
“honest_committed”: committed_honest,
“honest_total”: len(honest),
“agreed_digest”: agreed,
}

async def latency_sweep(
n: int = 10,
max_malicious: Optional[int] = None,
trials_per_point: int = 5,
timeout_s: float = 2.0,
net_cfg: Optional[NetConfig] = None,
seed: int = 7
):
if net_cfg is None:
net_cfg = NetConfig(min_delay_ms=5, max_delay_ms=35, drop_prob=0.0, reorder_prob=0.05)

if max_malicious is None:
max_malicious = n

results = []
random.seed(seed)

for m in range(0, max_malicious + 1):
latencies = []
successes = 0
agreements = 0

for t in range(trials_per_point):
out = await run_single_consensus(
n=n,
malicious=m,
net_cfg=net_cfg,
timeout_s=timeout_s,
seed=seed + 1000*m + t
)
results.append(out)
if out[“success”]:
successes += 1
latencies.append(out[“latency_s”])
if out[“agreed_digest”]:
agreements += 1

avg_lat = sum(latencies)/len(latencies) if latencies else None
print(
f”malicious={m:2d} | success={successes}/{trials_per_point} ”
f”| avg_latency={avg_lat if avg_lat is not None else ‘NA’} ”
f”| digest_agreement={agreements}/{successes if successes else 1}”
)

return results

def plot_latency(results: List[Dict[str, object]], trials_per_point: int):
by_m = {}
for r in results:
m = r[“malicious”]
by_m.setdefault(m, []).append(r)

xs, ys = [], []
success_rate = []
for m in sorted(by_m.keys()):
group = by_m[m]
lats = [g[“latency_s”] for g in group if g[“latency_s”] is not None]
succ = sum(1 for g in group if g[“success”])
xs.append(m)
ys.append(sum(lats)/len(lats) if lats else float(“nan”))
success_rate.append(succ / len(group))

plt.figure()
plt.plot(xs, ys, marker=”o”)
plt.xlabel(“Number of malicious (Byzantine) nodes”)
plt.ylabel(“Consensus latency (seconds) — avg over successes”)
plt.title(“PBFT Simulator: Latency vs Malicious Nodes”)
plt.grid(True)
plt.show()

plt.figure()
plt.plot(xs, success_rate, marker=”o”)
plt.xlabel(“Number of malicious (Byzantine) nodes”)
plt.ylabel(“Success rate”)
plt.title(“PBFT Simulator: Success Rate vs Malicious Nodes”)
plt.ylim(-0.05, 1.05)
plt.grid(True)
plt.show()

async def main():
n = 10
trials = 6
f = pbft_params(n)
print(f”n={n} => PBFT theoretical max f = floor((n-1)/3) = {f}”)
print(“Theory: safety/liveness typically assumed when malicious <= f and timing assumptions hold.\n”)

results = await latency_sweep(
n=n,
max_malicious=min(n, f + 6),
trials_per_point=trials,
timeout_s=2.0,
net_cfg=NetConfig(min_delay_ms=5, max_delay_ms=35, drop_prob=0.0, reorder_prob=0.05),
seed=11
)
plot_latency(results, trials)

await main()
